Product Description Kodak Alaris S2060w Scanner Part # 1015114 Scanner Specifications Recommended Daily Volume Up to 7,000 pages per day Throughput Speeds* Black-and-white/grayscale/color: up to 60 ppm / 120 ipm at 200 and 300 dpi Scanning Technology Dual CIS; Grayscale output bit depth is 256 levels (8-bit); color output bit depth is 24 bits (8 x 3) Processor Embedded Dual Core Cortex A15 Processors (1.5GHz) with Dual DSP (750 MHz) Image Processors with Multiple Cortex M4 Sub-processors Operator Control Panel 3.5-inch / 89 mm color touch screen LCD Optical Resolution 600 dpi Illumination Dual RGB LEDs Output Resolution 75 / 100 / 150 / 200 / 240 / 250 / 300 / 400 / 500 / 600 / 1200 dpi Max./Min. Document Size** 216 mm x 356 mm (8.5 x 14 in.) / 52 mm x 52 mm (2.08 in. x 2.05 in.) | Long document mode: 216 mm x 3,000 mm (8.5 in. x 118 in.) Paper Thickness & Weight 27–433 g/m² (7.2–160 lb. cover stock) | ID card thickness: up to 1.4 mm (0.55 in.) Feeder Up to 80 sheets of 80 g/m² (20 lb.) paper. Handles small documents such as A8, ID cards, embossed hard cards, and insurance cards (portrait and landscape orientations) Paper Feeding Detection Multifeed with ultrasonic technology, Intelligent Document Protection Connectivity USB 3.1 GEN1, Wireless Network 802.11 b/g/n and 10/100 Ethernet Software & Drivers Standard Software WINDOWS Bundled software: TWAIN, ISIS, WIA Drivers | Alaris Smart Touch | Alaris Capture Pro Software Limited Edition (via web download) Optional Software Alaris Info Input Solution | Alaris Capture Pro Software (Windows only) | Asset Management Software File Format Outputs Single and multi-page TIFF, JPEG, RTF, BMP, PDF, searchable PDF, TXT, PNG, CSV, Word and Excel Physical & Electrical Dimensions Weight: 3.3 kg (7.2 lbs.) | Depth: 204 mm (8.0 in.) not including input/output tray | Width: 312 mm (12.3 in.) | Height: 182.5 mm (7.2 in.) not including input tray | Depth with Input Tray: 269 mm (10.6 in.) | Height with Input Tray: 231.6 mm (9.1 in.) Electrical Requirements 100-240 V (International); 50-60 Hz Power Consumption Off: < 0.5 watts | Sleep mode: < 5.0 watts | Running: <36 watts Environmental Factors EPEAT Registered, ENERGY STAR Qualified | Operating Temperature: 10-35° C (50-95° F) | Operating Humidity: 15% to 80% RH Acoustical Noise Off or Ready mode: <20 dB(A) | Scanning: <50 dB(A) Recommended PC Intel Core i3 processor or faster, at least 4 GB RAM (Microsoft Windows) Accessories (Optional) Alaris Carrier Sleeves (5 PACK) Alaris S2000 Series Feed Roller Kit Alaris S2000 Series Stacking Deflector Accessory Alaris Passport Flatbed Accessory Alaris Integrated A4/Legal Size Flatbed KODAK A3 Size Flatbed *Throughput speed may vary depending on your choice of driver application software, operating system, PC and selected image processing features. **The maximum document size supported by the scanner will vary based on the output image resolution and image compression used. Browse more Kodak Alaris Scanners available at ScannerOne. For more information, visit Kodak Alaris.
