Description Norgren 5030 Solenoid Valve Series Features Norgren Development has developed a family of solenoid air valves specifically for severe-duty, high-temperature applications up to 250°F (125°C) continuous duty. 2007 EPA regulations required higher turbo boost pressures creating a hotter overall engine compartment. Cooling systems are designed to dissipate as much of this heat as possible. These valves anticipate the need for more robust component parts on and around the engine, targeting a particularly demanding application, the fan clutch solenoid valve. These valves, mounted in the engine compartment, are continuously energized in most installations. Key Value Robust component parts for use on and around the engine Designed for continuous duty in high temperature applications Integral Push-To-Connect (PTC) fittings Technical Data Operating pressure: 60 to 150 psi (5 to 10 bar) Operating temperature: -40°F – 257°F (-40°C – 125°C) -40°F to 200°F (5030 – 310B) Operating voltage: 9 to 16 volts Performance Application Three-way normally open and normally closed solenoid operated air valve designed for continuous duty under-hood, and chassis applications. Operating Temperature: -40°F- 257°F (-40°C- 125°C) Operating Voltage: 9 to 16 volts Drop Out Voltage: 0.5 volts Power: 0.30 amps at 12 volts, 68° F Resistance: 40 Ohms ± 10% at 68°F Pressure Rating: 60 to 150 PSIG (4.14 to 10.34 bars) Flow Rate: 2.76 SCFM minimum at 120 PSIG (8.27 bars) Equivalent Orifice: 0.047 diameter (CV = 0.042) Leakage: Less than 20 SCCM Air Connections: Integral 1/4″ push-to-connect fittings (meets SAE J2494-3, and FMVSS 571-106) Electrical Connections: Male 150 series connector to mate with Packard electric metri-pack 150 sealed connector, part number 12052641. Part Numbers: 5030-111 (Three-way NC, PTC fittings), 5030-211 (Three-way NO, PTC fittings), 5030-451 (Resistor suppression, PTC Elbow) Mounting: One 5/16″ or 8mm bolt. Part Marking: Part labeled with part number and date code. Source: https://cdn.norgren.com/pdf/5030_Next_Generation_Valve_09-15-14.pdf Additional sources: https://cdn.norgren.com/pdf/Solenoid_Valves_5030_Series.pdf Complete Norgren Catalog: HQ KSI authorized distributors with the complete line of Norgren parts, 2024 catalog.
