Technical Specifications Output Max Configurable Power (Watts) 1.425kWatts / 1.44kVA Output Frequency (sync to mains) 50/60 Hz /- 3 Hz Sync to mains Topology Line interactive Waveform type Sine wave Maximum Output Current 24 Bypass Internal bypass (automatic and manual) Input Input frequency 50/60 Hz /- 3 Hz Auto-sensing Input voltage range for main operations 75 – 154 Adjustable, 82 – 147V Number of Power Cords 1 Batteries & Runtime Battery type VRLA Typical recharge time 3hour(s) Replacement Battery RBC43 Expected Battery Life (years) 3 – 5 RBC Quantity 1 Battery Charge Power (Watts) 199Watts Extendable Run Time 1 Battery Volt-Amp-Hour Capacity 600 Extended Run Options APC-Smart-UPS-XL-Modular-1500VA-120V-Rackmount-Tower-Not-for-sale-in-Vermont- Runtime View Runtime Graph View Runtime Chart Efficiency View Efficiency Graph Communications & Management Interface Port(s) DB-9 RS-232, RJ-45 10/100 Base-T, SmartSlot, USB Pre-Installed SmartSlot™ Cards AP9631 Control panel LED status display with load and battery bar-graphs and on line : on battery : replace battery : overload and bypass indicators Audible Alarm Alarm when on battery : distinctive low battery alarm : configurable delays Emergency Power Off (EPO) Optional Surge Protection and Filtering Surge energy rating 540Joules Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 Physical Maximum Height 3.4inches (86MM, 8.6CM) Maximum Width 17.0inches (432MM, 43.2CM) Maximum Depth 26.7inches (678MM, 67.8CM) Net Weight 103.22lbs. (46.82KG) Shipping weight 125.27lbs. (56.82KG) Shipping Height 9.8inches (250MM, 25.0CM) Shipping Width 23.5inches (596MM, 59.6CM) Shipping Depth 38.6inches (980MM, 98.0CM) Color Black Units per Pallet 8.0 Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 0 – 95 % Operating Elevation 0 – 10000ft (0 – 3048meters) Storage Temperature -5 – 55 °C Storage Elevation 0 – 30000ft (0 – 9144meters) Audible noise at 1 meter from surface of unit 55.0dBA Online thermal dissipation 300.0BTU/hr Conformance Approvals BSMI, CSA, FCC part 15 class A, NOM, UL 1778, VCCI class A Equipment protection policy Lifetime : $150000 Standard warranty 2 years repair or replace Sustainable Offer Status RoHS Compliant PEP Available in Documentation tab EOLI Available in Documentation tab
