Technical Specifications Download Output Max Configurable Power (Watts) 300Watts / 600VA Output Frequency (sync to mains) 60 Hz /- 3 Hz Sync to mains Topology Line interactive Waveform type Stepped approximation to a sinewave Transfer Time 6 ms typical : 10 ms maximum Input Input frequency 60 Hz /- 5 Hz Input voltage range for main operations 88 – 143V Number of Power Cords 1 Type of Input Protection Required GL fuse Input Power Factor at Full Load 0.5 Batteries & Runtime Battery type Lead-acid battery Included Battery Modules 1 Typical recharge time 6hour(s) Replacement Battery APCRBC110 Expected Battery Life (years) 2 – 4 Battery Charge Power (Watts) 12Watts Battery Volt-Amp-Hour Capacity 75 Runtime View Runtime Graph View Runtime Chart Efficiency View Efficiency Graph Communications & Management Control panel LED Status display with on line : on battery Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm Surge Protection and Filtering Surge energy rating 160Joules Physical Maximum Height 141MM, 14.1CM Maximum Width 101MM, 10.1CM Maximum Depth 300MM, 30.0CM Net Weight 4.33KG Shipping weight 4.58KG Shipping Height 223MM, 22.3CM Shipping Width 143MM, 14.3CM Shipping Depth 347MM, 34.7CM Color Black Master Carton Dimensions (Length x Width x Height) 356 x 152 x 229MM Master Carton Weight 4.6 Pallet Dimensions 47 x 39 x 45inches Pallet Weight 892.87lbs. SCC Codes 40731304323189 Environmental Operating Temperature 0 – 40 °C Operating Relative Humidity 0 – 95 % Operating Elevation 0 – 609.6meters Storage Temperature -20 – 50 °C Storage Elevation 0 – 4572meters Audible noise at 1 meter from surface of unit 40.0dBA Conformance Approvals CTUVus, NOM Standard warranty 2 years repair or replace Sustainable Offer Status RoHS Compliant
