Technical Specifications Output Output power capacity 600Watts / 1.0kVA Max Configurable Power (Watts) 600Watts / 1.0kVA Nominal Output Voltage 120V Output Frequency (sync to mains) 60Hz /- 3 Hz Waveform type Stepped approximation to a sinewave Output Connections (6) NEMA 5-15R (Battery Backup) Transfer Time 6ms typical : 10ms maximum Input Nominal Input Voltage 110V, 120V Input frequency 60 Hz /- 5 Hz Input Connections NEMA 5-15P Cord Length 1.22meters Input voltage range for main operations 80 – 138 (Line to Neutral)V Number of Power Cords 1 Maximum Input Current 8.0A Input Power Factor at Full Load 0.6 Batteries & Runtime Battery type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof Included Battery Modules 1 Typical recharge time 6hour(s) Expected Battery Life (years) 2 – 4 Battery Volt-Amp-Hour Capacity 114 Runtime View Runtime Graph View Runtime Chart Efficiency View Efficiency Graph Communications & Management Control panel LED Status display with On Line : On Battery Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm Surge Protection and Filtering Surge energy rating 160Joules Physical Maximum Height 182MM, 18.2CM Maximum Width 130MM, 13.0CM Maximum Depth 320MM, 32.0CM Net Weight 8.2KG Shipping weight 9.0KG Shipping Height 197MM, 19.7CM Shipping Width 285MM, 28.5CM Shipping Depth 395MM, 39.5CM Environmental Operating Temperature 0 – 40 °C Operating Relative Humidity 0 – 95 % Operating Elevation 0-600meters Storage Temperature -20 – 50 °C Storage Relative Humidity 0 – 95 % Storage Elevation 0-4500meters Audible noise at 1 meter from surface of unit 40.0dBA Conformance Approvals NOM, TUV Standard warranty 2 years repair or replace Sustainable Offer Status RoHS Compliant REACH REACH: Contains No SVHCs
