DescriptionFeaturesG4X PlugIn Key Features (where applicable): Up to 6D fuel and ignition mapping Precision closed loop cam control (four cam, independent control) Sequential fuel delivery Digital triggering, all OEM patterns OEM idle hardware supported 5D boost control with three switchable tables Motorsport features – antilag, launch, flat shift Continuous barometric correction (on board) CAN port QuickTune – automated fuel tuning Individual cylinder correction USB tuning cable included Stats recording into on-board memory Gear compensations for spark, boost and fuel Real time selectable dual fuel, ignition and boost maps Sync and crank sensors can be a combination of Hall effect, variable reluctance or optical Boost control referenced to gear, speed or throttle position 512 mega bytes data logging memory Staged injection Knock with “windowing”I/O Expansion Options: The following expansion connector inputs/outputs are provided: Expansion connector 1 Gnd                Sensor Ground Only 5V Out        Low Current 5V Supply DI5                Digital Input DI6                Digital Input An Volt 8        Analog 0-5V input An Volt 2        Analog 0-5V input An Temp 3        Temperature sensor input An Temp 4        Temperature sensor inputExpansion connector 2 Gnd                Sensor Ground Only 5V Out        Low Current 5V Supply Ign 7                Ignition 7 Auxiliary Output Ign 8                Ignition 8 Auxiliary Output DI 9                Digital Input DI 10                Digital Input An Volt 10        Analog 0-5V input Aux 11                Auxiliary Output 11Download Manual
